FSP11

Description

Dimension 120(±0.5 mm) *180(±0.5 mm)*2.5mm (±0.5mm) Encapsulation method PET laminated Solar silicon crystal Single crystal Open circuit voltage 7.4V (-5%/+10%) Short circuit current 0.508A (-5%/+10%) Solar panel working voltage 5.75V (-5%/+10%) Working current 0.484A (-5%/+10%) Solar panel power Max Power(Ppm) 3W (-5%/+10%) Operating temperature -20℃to+60℃ Storage conditions Temperature -20℃~45℃, Humidity<60% Conversion rates 18.2%±2% Protection Level IP65 Connection with camera Micro USB
